Open Policy Agent (OPA)

Overview

Open Policy Agent (OPA) is an open-source policy engine integrated with FormKiQ to provide fine-grained access control. This integration enables organizations to define and enforce attribute-based access controls (ABAC) across their document management system.

Key Features

• Centralized policy management
• Fine-grained access control
• Attribute-based decisions
• Policy evaluation engine
• Site-specific configurations

note

OPA policy can be configured globally or per FormKiQ site

API Integration

Policy Management

Endpoint	Method	Description	Note
/sites/opa/accessPolicies	PUT	Configure OPA policy	Admins only
/sites/{siteId}/opa/accessPolicy	GET	Retrieve OPA policy	Admins only
/sites/{siteId}/opa/accessPolicy	DELETE	Remove OPA policy	Admins only

Configure Policy

{
  "policy": "string",
  "siteId": "string"
}

Policy Evaluation

Input Data Format

FormKiQ provides the following structure to OPA's decision engine:

{
    "resource": "<resource path specifies the endpoint>",
    "httpMethod": "<http method>",
    "pathParameters": "<map of parameters from the request URL>",
    "queryParameters": "<map of query from the request URL>",
    "user": {
        "username": "<user name>",
        "roles": "<string list of roles>"
    }
}

Example input for document access:

{
    "resource": "/documents/{documentId}",
    "httpMethod": "GET",
    "pathParameters": {
        "documentId": "fe03fe66-1338-4163-a86b-ab455202fd57"
    },
    "queryParameters":{
        "siteId": "default"
    },
    "user":{
        "username": "<email>@yourcompany.com",
        "roles": ["Admins"]
    }
}

Access Control Types

Role-Based Access Control (RBAC)

Example RBAC policy:

package formkiq

import future.keywords.if
import future.keywords.in

default allow := false

# Allow Admins role
allow if {
    "Admins" in input.user.roles
}

# Allow User Role in SiteId
allow if {
    input.queryParameters.siteId in input.user.roles
}

# Allow User Read Role in SiteId
allow if {
    input.httpMethod == "GET"
    concat("_read", [input.queryParameters.siteId, ""]) in input.user.roles
}

# Allow User Read Role in SiteId access to /search
allow if {
    input.httpMethod == "POST"
    input.resource == "/search"
    concat("_read", [input.queryParameters.siteId, ""]) in input.user.roles
}

Attribute-Based Access Control (ABAC)

ABAC enables access control based on resource attributes. These attributes can be managed through:

• POST /documents during creation
• POST /documents/{documentId}/accessAttributes
• PUT /documents/{documentId}/accessAttributes

note

Access attribute endpoints require Admin role

Example ABAC policy:

package formkiq

import future.keywords.if
import future.keywords.in

default allow := false

# Allow customer service access to specific document types
allow if {
    "customer_service" in input.user.roles
    data.documents.documentType = "customerService"
}

Limitations

Partial Evaluations

Some policy evaluations may require data store access, leading to "partial" evaluations. Key considerations:

1. Search Limitations

   • POST /search cannot complete partial evaluations
   • Use POST /searchFulltext or POST /queryFulltext instead

2. Performance Impact

   • DynamoDB optimizes for predictable access patterns
   • Complex attribute evaluations may affect performance

3. Best Practices

   • Design policies with data access patterns in mind
   • Use OpenSearch for complex attribute searches
   • Consider caching frequently accessed attributes
